Sectional gates

Sectional gates 2017-07-25T09:31:23+00:00

Секционные ворота FireTechnics

SECTIONAL GATES

Секционные ворота FireTechnics

MAIN ADVANTAGES

Sectional gates developed by FIRETECHNICS are inherent in a whole range of undeniable advantages, including: simplicity and comfort of use, safety, high reliability, excellent sealing of the opening and thermal insulation. Extensive selection of various kinds of additional accessories, types and shades of the panels makes it possible to select the gate for any industrial facility. At the same time, it is possible to install sectional gates both on routes where traffic is intensively moving, and in rooms characterized by an increased level of humidity, and in addition, to the openings of impressive dimensions. The gate structure “FIRETECHNICS” boasts a reinforced frame and in that it is made of materials with increased corrosion protection, which guarantees the reliability and safety of the products for a long period of operation.

SIX ARGUMENTS,

SAYING THE FIRETECHNICS GATEWAY INSTALLATIONS

надежность секционных ворот

EXCITING STRENGTH AND 100% RELIABILITY

надежность секционных ворот

The design of industrial gates is thought through to the smallest detail. All of their elements are designed for really intensive operation and use in the openings of impressive dimensions.
Sandwich panels made of steel, Filled with high-density polyurethane, guarantee the rigidity of the door leaf, their increased resistance to wind and shock effects .
The gate “FIRETECHNICS”, belonging to the ProPlus series, is capable of withstanding a load equal to 700 Pa, which corresponds to wind speed of 120 km. at one o’clock.

долговечность секционных ворот

DURABILITY, WHICH IS CONFIRMED BY PRACTICAL TESTS

долговечность секционных ворот

When creating products “ProPlus” used components with increased corrosion resistance, significantly extending the period of operation of the gate:

  • Intermediate hinges and roller brackets made of stainless steel;
  • Torsion springs and painted side lining;
  • Having a polyurethane coating, modified with polyamide particles, sandwich panels.

Multiple trial tests confirmed that the gate leafs are capable of lasting for 15 years without corrosion, even when installed in coastal areas.

энергоэффективность секционных ворот

FABULOUS ENERGY EFFICIENCY

энергоэффективность секционных ворот

Due to increased thermal insulation, the “FireTechnics” gates are able to provide comfortable temperature conditions for storage goods and people’s work.
We give the coefficients of resistance of the gate of heat transfer:

  • Series ProTrend (40 mm panel) – 0,87m2 C / Wt *;
  • ProPlus gate (45 mm panel) – 1,00m2 C / Wt *



The thermal insulation R, equal to 1,0m2 C / Bt, can be compared with a brick wall of 60-cm thickness.

гарантия безопасности секционных ворот

SAFETY WARRANTY

гарантия безопасности секционных ворот

“FireTechnics” is responsible for the safety of the use of its industrial gates.
Structurally the sectional gate is able to protect people from:

    • Opportunities to pinch your fingers;
    • From receiving cuts and hooks;
    • From uncontrolled movement of the gate;



  • From the possibility of the canvas to fall in the event of a cable tear, or breakage of the spring.



The gate meets all European safety requirements EN 12426, EN 12604, EN 12424, EN 12453, EN 12425.

секционные ворота для любого объекта

A PERFECT SOLUTION APPROACHING ANY OBJECTS

секционные ворота для любого объекта

The extensive range of industrial gates offered by the company “FireTechnics” gives an opportunity to choose the best solution for any object, taking into account the needs and wishes of the customer:

    • Due to increased thermal insulation, gates made of sandwich panels can be successfully used throughout Belarus and Russia and Ukraine, as well as in the Far North;



  • Elegant looking the gates made of aluminum are manufactured taking into account all trends in the architecture of modern industrial buildings.

возможности секционных ворот

WIDTH SETTING OPPORTUNITIES

возможности секционных ворот

10 types of installation, which allow the installation of sectional gates of premises that have any features of the opening: high ceilings low jumper, or inclined roof. The design of sectional gates with reinforcement and various types of balancing of the canvas allow the installation of the gate in the openings of impressive dimensions — Up to 800 × 700 cm.
The gates are manufactured individually under one or another opening, while the width-height step is 0.5 cm.

EXTENDED ASSORTMENT

широкий ассортимент секционных ворот
широкий ассортимент секционных ворот
широкий ассортимент секционных ворот

The Group of Companies “FIRETECHNICS” is pleased to offer an extensive range of gates for industrial facilities – the ProTrend and ProPlus series and from sandwich panels, as well as the panoramic gates FireTechnicsTherm, FireTechnicsPro
and FireTechnicsTrend.

High-strength and heat-resistant gates made of sandwich panels guarantee excellent thermal insulation and reliability for years to come. Elegant panoramic gates made of organic glass and aluminum are designed to embody the fashionable architectural solutions.

широкий ассортимент секционных ворот

ProTrend

Practical and safe gate from Sandwich panels of 40 mm thickness with fittings, Made of galvanized steel. ProTrend gates offered to an affordable price are designed specifically for operation in various industrial facilities with heavy loads. Gates guarantee the safety of operation: the standard set includes all the necessary safety systems, for which you do not have to pay extra. Springs have a resource of twenty-five thousand cycles and a high-strength construction designed for long-term operation.
Using ProTrend is a reasonable savings and your security guarantee.

Made of aluminum sections of 4-centimeter thickness, panoramic gates under the brand FireTechnicsTrend give the opportunity to create truly original facade compositions and budget savings.

Specifications:

Comparable to a brick wall, having a thickness of 57 cm.

  • Sandwich panels are 40 mm thick;
  • The coefficient of resistance to heat transfer is 1.0 m2 C / W;
  • Intermediate hinges and roller brackets are made of galvanized steel;
  • Products comply with all European safety standards;
  • The resource of springs is 25 thousand cycles of “lifting-lowering”;
  • The maximum allowable size is -700 × 600 cm.

ProPlus

They are distinguished by the heat, strength and reliability of the gate from the joint venture, having a thickness of 4.5 cm, guaranteeing good thermal insulation of any premises. The ProPlus gate can be mounted even in areas that are characterized by cold climatic conditions, including in the Far North. Roller brackets, together with intermediate loops made of stainless steel, boast increased corrosion resistance, which makes it possible to operate the gate in high humidity conditions – for example, in car washes, in Industrial as well as in coastal areas.

The choice of clients is offered two series of quality panoramic gates: made in the spirit of the classics of FireTechnicsPro and famous for the increased thermal insulation of FireTechnicsTherm.

Specifications:

Comparable to a brick wall having a thickness of 60 cm.

  • Sandwich panels have a thickness of 45 mm;
  • The coefficient of resistance to heat transfer is 1.0 m2 C / W;
  • Intermediate hinges and roller brackets are made of galvanized steel;
  • Products comply with all European safety standards;
  • The resource of springs is 25 thousand cycles of “lifting-lowering”;
  • The maximum permissible size is -800 × 700 cm.
широкий ассортимент секционных ворот
широкий ассортимент секционных ворот

DIFFERENT SECURITY AND PRACTICALITY OF THE GATEWAY ProTrend

широкий ассортимент секционных ворот

YOUR REASONABLE SAVINGS AND ENHANCED RELIABILITY

In these gates, strong Sandwich panels are used, having a thickness of 4 centimeters. The closed contour of the panel provides a reliable protection against stratification due to solar heating and when the gate is overly closed.

Without any additional surcharge, the gate is equipped with protection mechanisms preventing the possibility of a fall of the blade in the event of a breakdown of the spring and breakage of the cable. This serves as a guarantee of safe operation of the gate data.

Types of panels for the construction of the gate ProTrend

широкий ассортимент секционных ворот

In the standard basic set for the purpose of balancing the canvas, torsion springs are used, whose life is of the order of twenty five thousand cycles. If the customer has a desire, it is possible to increase the spring resource to 100 thousand cycles.

Maximum allowable gate size:
At a width of 700 cm. The height is 600 cm.

Ten standard shades WITHOUT ADDITION

цвета секционных ворот

The colors are close enough to those given in the RAL scale.
Depending on the client’s desire, both sides can be painted in any other RAL shade.

цвета секционных ворот
панорамные ворота
широкий ассортимент секционных ворот

PRACTICAL PANORAMIC GATES FireTechnicsTrend

панорамные ворота

GATE WITH ORIGINAL AND INDIVIDUAL DESIGN

панорамные воротаThanks to the use of a new design of double-glazed windows, the products provide:

  • Increased sealing;
  • Resistance to various deformations;
  • Remarkable thermal insulation qualities.

FireTechnicsTrend – panoramic gates made of aluminum profiles with a thickness of 40 mm and hardware made of galvanized steel at an affordable price. An extensive range and variety of color palette – these are the main advantages of the gate series FireTechnicsTrend.

Variations of filling the gate of the FireTechnicsTrend model

двойное остекление

A modern, shockproof material with maximum transparency is used.

двойное остекление

The panel is made from two aluminum sheets with stucco stamping and inside is filled with polystyrene insulation.

защита остекления от появления царапин In order to ensure protection of the glazing from scratching is applied SAN-plastic, which has a special anti-abrasive coating.

Even after experiencing multiple cleansing, this glazing can boast maximum transparency.

Panoramic sections produced by the company fit well with sandwich panels of 4 cm, so that the combined fabric can boast of a harmonious appearance.

панорамные секции ворот

To expand the possibilities of using panoramic gates, special grilles are called, which can be put, replacing glazing.
This can be a good solution for equipping parking lots.

Стальная решетка Тянутая стальная решетка.Перфорированный алюминиевый лист
Lattice made of steel 4 × 4 cm.
Ventroresis has a cross-section of 83%
Stretched steel grating.
Ventroresis has a cross-section of 58%
Aluminum sheet with perforation 8-12mm. Ventroresis has a cross-section of 40%

Nine standard shades are PROVIDED WITHOUT APPRAISAL

цвета ворот

These shades have a fairly close match with the traditionally used RAL scale.
If the customer ordering the gate wants to paint them on both sides in a different color RAL, we will gladly meet him.

цвета ворот
теплые ворота
теплые ворота

HIGH-STRENGTH AND PRESENT HEAT GATES ProPlus

теплые ворота

EXCITING DURABILITY AND EFFECTIVE THERMAL INSULATION

The gates of the ProPlus model are made of sandwich panels having a thickness of 4.5 cm, providing increased thermal and strength properties.

The high-strength and very warm joint venture enables the ProPlus structures to be mounted even in rooms that have strict thermal insulation requirements, and in addition, in areas with increased wind load. Such gates can be manufactured in large sizes – up to 800 × 700 cm.

Varieties of panels for portal structures ProPlus

Разновидности панелей для воротных конструкций ProPlus

Balancing of the canvas is made by means of a single-shaft or two-pronged system, proceeding from the dimensions of the gate.

The spring resource is equal to 25 thousand cycles of “lifting-lowering” with the possibility to increase the parameter to 100000 cycles.

Maximum possible gate size:
At a width of 800 cm, the height is 700 cm.

Ten standard colors are provided WITHOUT APPRAISAL

цвета секционных ворот

The colors closely correspond to the RAL scale.
If the customer wishes, the gate on both sides will be painted in any other color from the RAL table.

цвета секционных ворот
панорамные ворота FireTechnicsPro

PANORAMIC GATES WITH EXTENDED FUNCTIONALITY FireTechnicsPro

панорамные ворота

FireTechnicsPro: ELEGANCE AND PRACTICALITY AT REASONABLE PRICE

панорамные воротаNew design of double-glazed windows provides:

  • Improved sealing;
  • Resistance to deformation;
  • Excellent thermal insulation properties;
  • Protection against scratches.

FireTechnicsPro – high-strength panoramic gates, characterized by reliability and functionality, made of aluminum, and providing an extensive selection of glazing and accessories.

FireTechnicsPro fill pattern variations

двойное остекление

A modern, shock-proof material with enhanced transparency is used.

одинарное остекление

A progressive shock-resistant material with increased transparency parameters is used.

алюминиевое заполнение

The panel is made of a pair of aluminum sheets with stucco embossing and is filled with polystyrene.

алюминиевое остекление

The panel can be made from a pair of aluminum sheets without embossing and have a polyethylene filling (under high pressure).

Structural heads completely repeat the design of the joint venture, due to which the panoramic panels are easily combined with sandwich panels with microwave and S-ribs.

панорамные секциионные ворота

In order to expand the possibility of using panoramic gates, you can use special grills, if necessary, mounted instead of traditional glazing.
This can be a good solution when equipping the parking lots.

Стальная решетка Тянутая стальная решетка.Алюминиевый лист с перфорацией 8–12 мм.
Lattice made of steel 4 × 4 cm.
Ventroresis has a cross-section of 83%
Stretched steel grating.
Ventroresis has a cross-section of 58%
Aluminum sheet with perforation 8-12 mm.
Ventroresis has a cross section of 40%

Ten standard colors are provided WITHOUT APPRAISAL

цвета ворот

These colors closely correspond to the RAL scale.
If there is a customer’s desire, on both sides the gate will be painted in a different color RAL, or shade ADS703.

цвета ворот
теплые панорамные ворота
панорамные ворота с улучшенной теплоизоляцией

PANORAMIC GATES WITH IMPROVED THERMAL INSULATION FireTechnicsTherm

FireTechnicsTherm панорамные ворота теплые

FireTechnicsTherm: AESTHETIC APPEARANCE AND EFFECTIVE HEAT SAVING

панорамные воротаUpdated design of double-glazed windows guarantees:

  • Better sealing;
  • Resistance to all kinds of deformations;
  • Remarkable thermal insulation qualities;
  • Protection from scratches.

FireTechnicsTherm – a warm gate made of aluminum, which not only looks presentable, but also capable of providing a highly reliable thermal insulation of any premises.

Variations of gate filling of the FireTechnicsTherm model

тройное остекление

It uses a modern protection against impact material, which has maximum transparency.

двойное остекление

It uses a modern protection against impact material, which has maximum transparency.

алюминиевое заполнение

The panel is made of a pair of aluminum sheets with stucco stamping on them and filled with polystyrene.

защита остекления от появления царапин The protection of glazing from possible scratches guarantees the use of SAN-plastic with special anti-abrasive coating.
As a result, provides maximum transparency of the glazing
For a long time, despite multiple cleansing.

Ворота модели FireTechnicsTherm

The gate of the FireTechnicsTherm model can be produced either completely on the basis of panoramic panels, or combined with sandwich panels S-corrugation and microwave.

The use of thermal bridges in the design of profiles contributes to improving the thermal insulation properties of the gate to 40 percent, and, therefore, provides an opportunity to significantly save on heating the premises.

Due to the presence of polyamide inserts, thermal profile separation
And the heat-insulating qualities of the panoramic gate are improved.

Four standard colors are provided WITHOUT APPRAISAL

цвета ворот модели FireTechnicsTherm

All colors have a close match to the RAL table.
If the customer wants, the gates made for him on both sides will be painted in a different shade of RAL.

прозрачные панорамные ворота
прозрачные панорамные ворота

PANORAMIC GATES WITH MAXIMAL TRANSPARENCY

прозрачные панорамные ворота

GOOD NATURAL LIGHTING
AND A WONDERFUL OVERVIEW

Panoramic gates with a large area of glazing – a modern combination of organic glass and metal, simplicity
And conciseness of forms in combination with the functionality of sectional gates.

Panoramic gates with solid glazing have maximum transparency, filling the rooms with natural light. Such gates are perfect for shops and car dealers, allowing them to showcase their products.

прозрачные панорамные ворота
прозрачные панорамные ворота

FireTechnicsPro

FireTechnicsTrend

FireTechnicsTherm

  • Gates can be made up to 300 cm wide without an impost.
  • The construction of the gate up to 500 cm can be made with one impost.

ProTrend
ALWAYS AVAILABLE, DIFFERENT BY SAFETY AND RELIABILITY OF THE GATE

The use of advanced technologies, coupled with many years of successful manufacturing experience, enables us to create gates with a number of undoubted advantages. Sophisticated design to the smallest detail and the use of high-quality components ensure the attractiveness of the exterior design, reliability and security of the ProTrend gate operation for long, long years.

энергоэффективная конструкция ворот

Corner racks are inherently hidden installation: they are mounted behind the opening and do not have contact with the street, because they can not conduct cold in the premises. Due to the lack of freezing elements, ProTrend portal structures can boast an enviable thermal insulation.

Надежная защита от сквозняков ворот

Thanks to the roller brackets, it is possible to achieve a really tight fit of the door leaf to the opening, which excludes the possibility of drafts and guarantees improvement of the thermal insulation of the room.

Беспроблемная многолетняя служба ворот

The spring resource is designed for 25 thousand lifts and descents, which is corresponding to seventeen years of service, with the condition of daily opening and closing four times.
For a more intensive and long use of the gate, it is recommended to put springs with a resource of about 100,000 lifts and descents.

гарантированная безопасность ворот

In the standardized purchase of industrial gates, a device that blocks their web when a spring breaks occurs, preventing it from falling, is turned on. The use of specialized lower brackets prevents the lowering or falling of the door leaf when the rope breaks suddenly.

удобство монтажа ворот

A coupling with the possibility of adjustment makes it possible to turn the gross parts relative to each other, achieving uniform cable tension, which provides great convenience for installation.

прочность соединения ворот

When equipping the rail system, high-strength and reliable rovings are used. They do not damage the galvanic anticorrosion coating of the profiles. In addition, the absence of protrusions ensures the smooth movement of the rollers.

ProPlus
STRONG, VERY WARM AND LONG-TERM GATES

The gates belonging to the ProPlus series are the optimal solution for the arrangement of energy-efficient buildings or for individual rooms whose conditions are high in humidity. Having all the advantages inherent in the ProTrend series, such gates significantly expand the possibilities of its use due to improved thermal insulation characteristics, high strength and resistance to corrosion.

улучшенная теплоизоляция ворот

The panel, which has a thickness of 45 mm becomes the key to providing excellent thermal insulation. At the same time, the coefficient showing the resistance to heat transfer of the ProPlus structure is equal to 1.06 m2 ° C / Bt, which is equivalent to the thermal insulation of the brick wall of 65-cm thickness.
As a result, such gates remarkably retain heat, ideally suited for premises, to the temperature regime in which strict requirements are imposed.

высоконадежная герметизация ворот

To seal the opening along the gates, there are seals of elastic and frost-resistant material – EPDM. The multi-chamber sealant placed below is designed to protect against the possibility of ingress of atmospheric precipitation. The stops provide protection of the lower seal against excessive clamping and protect the optical sensors from damage.

устойчивость к коррозиям ворот

Intermediate hinges and roller brackets made of stainless steel and having excellent anti-corrosion properties.
Due to the multilayered coating of the panels and the color of the side panels, the canvas installed in the gate “FIRETECHNICS” is able to withstand “salt fog” for seven hundred and fifty thousand hours, corresponding to fifteen years of operation in the difficult conditions of the coastal zones
Or “dirty” industrial areas.

надежность соединения панелей ворот

Thanks to the special form of the intermediate loops – “bent sheet” – they have an enviable strength and guarantee the reliability of the connection of the portal sections. As shown by practical tests, one intermediate loop is able to withstand the tensile load of 7000N, or 715kg. Skewing and sagging of these loops are completely impossible.

повышенная ветрокстойчивость ворот

Increased thickness Sandwich Panels – this is the basis of strength and durability of the gate to shock and wind loads. 4-th class of wind resistance in accordance with
EN 12424 – these gates are able to withstand winds blowing 120 km / h, which is confirmed by tests carried out at the Rosenheim Institute.

беспроблемная ворота ворот

If the width of the opening is more than five meters, the gate is equipped with roller duplex brackets and special profiles, which give the canvas a good stiffness. The reinforced package is delivered without making a surcharge and makes it possible to provide a truly trouble-free operation of the large weight gate for many years in conditions of increased operational loads.

система балансировки ворот

TWO-WAVE SYSTEM
GATEWAY BALANCING

система балансировки ворот
система балансировки ворот

OUR IMPRESSION SOLUTIONS
FOR NON-ORDINARY PROJECTS

большие ворота

STRENGTH AND RELIABLE DESIGN OF GREAT GATES

Two-shaft balancing system leaf allows to make Sectional gates of large dimensions. These gates can be installed on such objects as private aviation hangars or railway entrances.

Gates of large sizes are supplied with wide side plates and duplex roller brackets, which guarantees a good work under heavy loads.

Specialized reinforcing profiles provide Gate strips additional rigidity, preventing the deformation of sandwich panels in the case of severe temperature and humidity fluctuations, and in addition, with increased wind load.

большие ворота

INCREASED OPERATING RESOURCE AND GUARANTEED SAFETY

Spring resource is at least 25 thousand lifts-descents. If necessary, it can be increased to 100 thousand cycles. Springs are made of painted steel. On each of them a ratchet reinforced clutch is installed, blocking the blade, if suddenly the spring breaks. Automated gates without any additional payments are equipped with specialized fault sensors, monitoring the operability of cables and springs. In the event of a breakdown of the spring, or a wire breakage, the movement of the gate will stop.

A TWO-WAVE SYSTEM RESPONSIBLE FOR THE BALANCE OF BEAMS

In order to transfer between the two torque torsion shafts, a chain equipped with a tensioner is used. The inherent chain system has a ratio of 1 to 1 and is responsible for synchronous rotational rotation. This serves as a guarantee for smooth and precise operation of the torsion mechanisms and excellent balancing of the door leaf.

большие ворота
встроенная калитка ворот

EQUIPMENT BUILT-IN WALLS – CONVENIENT AND PRESENT PRACTICAL SOLUTION

калитка секционных ворот
функциональность секционных ворот

MAXIMUM COMFORT AND WIDE FUNCTIONALITY

By means of the built-in wicket it is possible to enter and exit from this or that premise, without opening for this gate. The solution of such a plan provides operational convenience, saves force and gate resource.

Comfort, as you know, is born in the smallest details, therefore the design of the gate in the design of the gate is thought out to the smallest detail. Thanks to the plastic catchers the possibility of sagging the flaps is excluded, the canopy reliably protects from the possibility of moisture entering the interior, and a comfortable metal handle Can serve for decades.

The presence of a linear door closer makes the use of the wicket as comfortable as possible, and plastic plugs ensure the absence of gaps between the profiles and prevent finger pinching..

высота порога ворот

VARIOUS VEHICLES DIFFERENCES

Wicket, equipped with a flat threshold of 2 cm. Due to the flat threshold form, it is possible to transport work equipment through the wicket without hindrance. This threshold is made of an aluminum extruded profile, painted in shade RAL 9005 (black). Mounted such a gate to the gate ProTrend, ProPlus, FireTechnicsPro, having a combined view of the canvas up to 500 centimeters wide.

калитка ворот 100ммWicket, equipped with a low threshold of 10 cm
is installed in the gates of ProTrend, FireTechnicsPro and ProPlus,
Having a combined view of the canvas and a width of up to 450 centimeters. Wickets with flat or low thresholds meet the requirements of fire safety and are able to act as an evacuation exit from a building or premises.

калитка ворот 145ммWicket, equipped with a standard paddle 14.5 cm
it is put into the gates of ProTrend, ProPlus, FireTechnicsPro, which have a combined view of the canvas, whose width is more than 450 cm. This wicket can boast of reinforced construction and the possibility of installing larger sections in sectional gates.

калитка ворот 149ммWicket, equipped with a standard threshold of 14.9 cm
is placed in the panoramic gate of the FireTechnicsPro model (with the exception of combined filling).
A sufficiently high 14.9 cm threshold guarantees durability and high reliability of the entire gate structure, supplemented by a built-in wicket door.

Wicket colors

The tone of the wicket handle coincides with the color of its frame.

Коричнево-серый

Brown-gray
(Achieved by applying a powder coating, approximate in color to RAL 8019)

Металлик серебристый

Metallic silver
(It has an anodized coating, whose tone is A00-D6)

цвета калитки согласно каталогу RAL.

If the customer wishes, the wicket can be painted in any other colors, according to the RAL catalog.

GATEWAY WITH SIDE DOOR – HARMONY OF STYLE AND FUNCTIONALITY

Thanks to the side door and sectional gates in a single style, they fit harmoniously into the building facade, serving as an excellent complement to each other.

The frame together with the box at the side door are made of aluminum – extruded profiles.
Such a gate has the widest variety of designs: it can have left and right opening, open inside, or out.

The built-in or invoice mounting options allow you to install the gate in absolutely any opening, taking into account the wishes of the customer. The entire gate perimeter is provided with elastic polyurethane seals, which guarantee the sealing integrity of the opening.

VARIATIONS
EXECUTION

Standard shades of wicket profiles:

  • Silver (similar to RAL 9006);
  • White (similar to RAL 9016);
  • Gray-brown (similar to RAL 8019).

If the customer wishes, you can paint the profile of the wicket and in other shades in accordance with the catalog RAL.

калитка ворот
калитка ворот

Ten standard colors approximating RAL

калитка ворот
калитка ворот

Ten standard colors approximating RAL

калитка ворот
калитка ворот

Ten standard colors approximating RAL

калитка ворот
калитка ворот

Nine standard colors, close to RAL

ПРОМЫШЛЕННЫЕ ВОРОТА: ДОПОЛНИТЕЛЬНЫЕ ВОЗМОЖНОСТИ

INDUSTRIAL GATES: ADDITIONAL OPPORTUNITIES

ПРОМЫШЛЕННЫЕ ВОРОТА: ДОПОЛНИТЕЛЬНЫЕ ВОЗМОЖНОСТИ
ПРОМЫШЛЕННЫЕ ВОРОТА: ДОПОЛНИТЕЛЬНЫЕ ВОЗМОЖНОСТИ

EXTENDED CHOICE OF ACCESSORIES

Together with the purchase of the FIRETECHNICS model doors, consumers have access to a wide range of accessories. Preoptions provide an opportunity to give the gates an original look, taking into account all the wishes of the customer, to provide increased comfort and security of property, and in addition, to prolong the service period of the gate even under the most severe operating conditions.

Опции промышленных секционных ворот

A KIT FOR THE PREMISES WITH HIGH HUMIDITY

For gates operated in rooms where there is a high humidity, for example, at car washes,
Our company is pleased to offer a specialized anticorrosion kit. It includes a protective coating, which is processed by guides, roller axes, cables and hardware made of stainless steel.

Опции промышленных секционных ворот

Reliable lock

When installing products in rooms that do not have an additional entrance, it is recommended that they be provided with a bolt lock. It will enable the opening and closing of the gate both from the outside and from the inside.

Опции промышленных секционных ворот

PROTECTION AGAINST UNAUTHORIZED ACCESS

Improve security and increase the security of the premises from hacking is capable of a special anti-burglary device – so-called. Protection from jacking. In the case of an unauthorized attempt to raise the gate, this device will securely block the canvas and prevent intruders from entering the premises.

Опции промышленных секционных ворот

WINDOW

The presence of natural light in a room provided by windows is always an additional advantage. We offer different options for the windows, which will allow you to significantly save on artificial lighting of various types of warehouses and production halls, as well as harmoniously fit into the architectural appearance of any buildings.

Автоматические секционные ворота
Автоматические ворота

INSTALLING AUTOMATIC GATES – YOUR COMFORT AND SAFETY

автоматические секционные ворота

OUR SMART GATES

Автоматические ворота

Powerful electric drives allow you to automate large sectional gates, guaranteeing an increased intensity of operation. They are mounted directly on the torsion shaft.

The automatic gates are easily controlled from a special keypad or via radio control.
Elements that make up the warning and safety system – traffic lights, signal lamps, photocells, so-called. Optosensors and many others. Etc. – all this ensures the safe operation of the gate.

Автоматические ворота удобны в эксплуатации

CONVENIENT
EXPLOITATION

Надежность автоматических ворот

Safety

Надежность автоматических ворот

RELIABILITY

Широкий функционал автоматических ворот

WIDE
FUNCTIONAL

Широкий функционал автоматических ворот

ADAPTATION
TO THE AGGRESSIVE OPERATING CONDITIONS

In the vast assortment of “FireTechnics” there are brands of automated systems that can satisfy customers’ requests in any price categories.

MARANTEC – high quality and proven for years operation German automatic. Reliable and truly powerful drives belonging to the STA series: With a simple and very economical management unit AS210 , or an external management unit CS300, which boasts of broad functionality.

AN-MOTORS – Automated from FIRETECHNICS, belonging to the ASI series, offered to consumers at very affordable prices.

Drive sets STA, equipped with built-in management unit:

  • Can be used even in humid rooms (moisture protection IP65).
  • Equipped with manual mechanically unlocking and chain for emergency control.
  • The equipment is delivered in the complete set.

STA drives equipped with an external control unit CS300:

  • Can be used even in humid rooms (moisture protection IP65).
  • Equipped with a chain for emergency control.
  • Have extensive functionality.

ASI drive kits with outdoor control unit:

  • Equipped with manual mechanically unlocking and chain for emergency control.
  • Equipment is included.

PERFECTION OF THE SANDWICH-PANEL CONSTRUCTION

Сендвич панельABSOLUTE SAFETY
The intelligent design of the panels from “FIRETECHNICS” guarantees a high degree of security From pinched hands and fingers, i.e. meeting the indispensable requirement of European safety standards (According to EN 12604).

прочность крепленийSTRENGTH OF MOUNTINGS
The places where the self-tapping screws are fastened are located in the zone of joining the inner and outer sheets (4-re metal layer). As a result, fastening is maximally strong. The reliability of joining steel sheets completely eliminates the possibility of panel delamination in the case of a sharp
lowering the gate.

преимущества сендвич панелейCLOSED CURVE OF THE PANEL CONTROL
Both the inner and the face sheets of steel sandwich panels are connected between themselves in the upper and lower parts. This does not allow the panels to delaminate with solar heating, which is especially important for the regions in the south, as well as for portal structures painted in dark colors.

BASIS OF RELIABILITY AND SAFETY OF OPERATION OF INDUSTRIAL GATES

0
PROTECTION AGAINST VOICES
The application of an adhesive lacquer with a layer of 12 μm ensures a remarkable adhesion of the steel sheets to the foam, protects the panels from swelling by exposure to solar heating.
0
STABILITY TO CORROSION
The presence of a polyurethane coating, having a thickness of 20-25 μm, and a primer layer of 5-7 μm – is the basis of increased corrosion resistance of the panel. Galvanizing steel sheets in 16 microns provides anti-rust protection.
0
DURABILITY OF COVERING
On the outside of the panel, an optimal polyurethane coating is applied, which is modified with particles of polyamide (PUR-PA):

  • Can boast the highest resistance to the formation of scratches and other damages in the case of mechanical impact;
  • Perfectly tolerates temperature and humidity fluctuations;
  • Has high elasticity and hardness;
  • Has excellent anticorrosive properties;
  • Exhibits enviable resistance to chemicals and detergents.

HIGH ENERGY EFFICIENCY
ECONOMICITY AND COMFORT

Thanks to the thermal insulation efficiency of the sectional gates produced by the FIRETECHNICS their owner can save energy and ensure the comfort of the temperature in the room.

The highest thermal insulation qualities of industrial gates are due to their design features that ensure
Maximum possible energy savings.

Type of used gateCoefficient of resistance to heat transfer *, m2 C / W
ProPlus1
ProTrend0,87
FireTechnicsTherm, Triple glazed0,36
FireTechnicsPro, Having a double glazing0,22

* For gates measuring 500 × 500 cm on the basis of tests carried out at the Rosenheim Institute.

0
Panel thickness is the determining factor for the resistance parameter of the gate heat transfer. The thicker it is, the higher the resistance to heat transfer.
0
Due to the fact that the space between the steel sheets of the panels is filled with foamed polyurethane, the whole construction of the gate is guaranteed good thermal insulation parameters.
0
It is worth noting the supply of panels EPDM-sealant, able to maintain high strength and elasticity, even at low temperatures. Possessing high wear resistance, it can boast also non-hygroscopicity, resistance to aggressive substances and precipitation.
0
To seal the opening from the top and sides, 2-groin seals are used, made of EPDM, which has a different elasticity. The 2nd lobe of this seal guarantees extra protection against heat losses. The bottom seal, due to the ergonomic shape, conceals the unevenness on the floor and tightly seals the opening at the bottom.
0
Due to the thermal separation of profiles in the gates of the FireTechnicsTherm model, the thermal insulation of the panoramic gates (by as much as 40%) is significantly improved, which results in a comfortable temperature in the room without damage to the architectural stylistics of the building. The use of triple or double glazing displays the thermal insulation of the gates to a qualitatively new level.

SPECIFICATIONS

The maximum size of the gateWidth in mm
Width in mm
Sandwich panelsThickness, in mm
ViewSandwich panel made of steel
Panel made of aluminum with triple glazing of acrylic 25 mm
Aluminum panel with double glazing 26 mm
Aluminum panel with double glazing 22 mm
Aluminum panel with single glazing 3 mm
Panel made of aluminum with composite filling 26 mm thick
Panel made of aluminum with composite filling 22 mm thick
Panel made of aluminum with a composite filling thickness of 3 mm
Panel made of aluminum with a grating made of galvanized steel 40 × 40 mm. The cross-section of vent-slits is of the order of 83%.
The panel is made of aluminum with a drawn grid, made of galvanized steel. The cross-section of vent-slits is about 58%.
Panel made of aluminum in the form of a perforated sheet (perforation of the order of 8-12 mm) The cross-section of the ventrices is about 40%.
Drawing
Balancing systemTorsion springs (single-shaft system)
Torsion springs (double-shaft system)
WicketFitted with a flat threshold of 20 mm in height, the maximum size, in mm
Fitted with a low spout of 100 mm, the maximum size, in mm
Equipped with a standard paddle in 145 mm, the maximum size, in mm
Equipped with a standard paddle of 149 mm, the maximum size, in mm
Locking deviceLock bolt (included in standard gate)
Lock
The system that protects from jacking*
Various security systems (included in the standard version of the gate)The system providing protection against falling of cloths at sudden breakage of a spring
The system that protects against falling of canvases when a cable is cut
Finger blocking system
The system protecting from cuts and hooks

* For gates equipped with a bulk electric drive.

ворота ProPlus, ProTrendворота ProPlus, ProTrendворота FireTechnicsTrend, FireTechnicsPro, FireTechnicsThermворота FireTechnicsTrend, FireTechnicsPro, FireTechnicsThermворота FireTechnicsTrend, FireTechnicsPro, FireTechnicsTherm
ProPlusProTrendFireTechnicsTrendFireTechnicsProFireTechnicsTherm
80007000700070007000
70006000600060006000
4540404545
+++++
++
+++++
++
+++++
++
++
++
++
Microwave, S-ribbedMicrowave, S-ribbedMicrowave, S-ribbedMicrowave, S-ribbedMicrowave, S-ribbed
+++++
++++
+, 5000×7000+, 5000×6000+*, 5000×6000
+, 4500×7000+, 4500×6000+*, 4500×6000
+, 7000×7000+, 7000×6000+*, 7000×6000
+, 7000×6000
+++++
+++*+*+*
+++++
+++++
+++++
+++++
+++++

* For combined fabrics with a bottom sandwich panel.

типы монтажа секционных ворот

KINDS OF MOUNTING
AND THE HEIGHT OF THE INTERMEDIATE (MINIMUM)

Single-axis system

типы монтажа секционных ворот

Low

With a height of 230mm without a gate and a height of a bridge of 250mm with a gate

типы монтажа секционных ворот

Vertical installation with lower gross position

H = RM + 340mm

типы монтажа секционных ворот

Standardized With a jumper height of 410mm

типы монтажа секционных ворот

Inclined With the height of the jumper 490mm

типы монтажа секционных ворот

High with top gross position

The height of the bridge is 900mm

типы монтажа секционных ворот

Sloping high with a gross location on top

The height of the bridge is 900mm

типы монтажа секционных ворот

Tall, Having a height of 1795 mm in cross-section with a lower gross position

типы монтажа секционных ворот

Tilted high with a gross location below

The height of the jumper is 1795mm

типы монтажа секционных ворот

Vertical with gross arrangement from above

H = RM + 340mm

типы монтажа секционных ворот

Low reclining H = 275mm

H denotes the minimum height at which the jumper is located, in mm. RM is the height of the opening.

типы монтажа секционных ворот

Two-shaft system

типы монтажа секционных ворот
типы монтажа секционных ворот

Inclined With a jumper height of 920mm

типы монтажа секционных ворот
типы монтажа секционных ворот

High inclined With the top gross position and the height of the bridge is 720mm

типы монтажа секционных ворот
типы монтажа секционных ворот

High inclined With the lower shaft position of the shaft and the height of the bridge is equal to 2100 mm

типы монтажа секционных ворот
типы монтажа секционных ворот
типы монтажа секционных ворот

S – required size of the lateral space
Needed for gates that have manual control (in places where corner posts are mounted). In this case, S is 110 mm

For gates equipped with a chain reducer (in places where corner posts are mounted) Smin is 240mm
Smax is 360mm

When installing automatic gates
(At the mounting locations of the torsion shaft), the minimum value of S is 310 mm, and Smax is 440 mm

H denotes the minimum height at which the jumper is located, in mm. RM is the height of the opening.
